Paramètres

• Model Name

  ZK-IWB65BE; ZK-IWB75BE; ZK-IWB86BE

• Screen Parameters

• Screen Size

  ZK-IWB65BE: 65 inch
  ZK-IWB75BE: 75 inch
  ZK-IWB86BE: 86 inch

• Screen Type

  ZK-IWB65BE: ADS
  ZK-IWB75BE: ADS
  ZK-IWB86BE: IPS

• Backlight

  D-LED

• Backlight Life

  30,000 hours (min.)(typ.)

• Resolution

  3840 × 2160 (pixels)

• Brightness

  400cd/m² (typ.)

• Contrast Ratio

  1200:1 (typ.)

• Response Time

  ZK-IWB65BE: 6.5ms
  ZK-IWB75BE: 8ms
  ZK-IWB86BE: 8ms


• Refresh Frequency

  60Hz

• Aspect Ratio

  16:09

• View Angle

  178°(H) / 178°(V)

• Display Colors

  1.07B(8bit+FRC)

• Bonding Technology

  The gap between tempered glass and screen is close to 0

• Touch Parameters

• Touch Technology

  Advanced infrared touch technology

• Touch Points

  Up to 40

• Touch Response Time

  ≤ 5ms

• Accuracy

  Center 90% touch area: 1mm

• Anti-Glare

  High transparent + Smooth + Anti-glare

• Glass Hardness

  9H (Pencil Hardness) ; 7(Mohs Hardness) Tempered Glass

• Writing Height

  ≤3mm

• System

• CPU

  Quad core A55

• GPU

  MaliG52 MP2

• Memory (RAM)

  4GB (8GB Optional)

• Storage (ROM)

  32GB (128GB Optional)

• Operating System

  Android 13.0 / Windows 11.0 (Optional)

• Connectivity

• Front Port

  USB 3.0*2
  Type-C (65W)*1
  Touch-USB*1
  HDMI2.0*1

• Bottom Port

  LAN IN/OUT*2
  RS232 IN*1
  MIC IN*1
  AUDIO OUT*1
  SPDIF OUT*1

• Side Port

  Touch-USB*2
  HDMI IN*2
  USB 2.0*1
  USB 3.0*1
  OPS Slot *1

• WiFi

  WiFi 5 (IEEE 802.11 ac/b/g/n)

• Bluetooth

  BT 5.1: 2.1+EDR/4.2/5.1

• Built-in peripherals

• Speaker

  2*16W

• Power

• Operating Power

  100 V ~ 240 V/AC, 50/60 Hz

• Standby power consumption

  <0.5W

• Average power consumption (Without OPS)

  ZK-IWB65BE: 200W
  ZK-IWB65BE: 300W
  ZK-IWB65BE: 380W

• Physical

• Dimensions (W × H × D)

  ZK-IWB65BE: 1482.1×87.7×897.4 mm
  ZK-IWB75BE: 1716.5×87.7×1031.8 mm
  ZK-IWB86BE: 1967.8 x87.7.x1169.9 mm

• Net Weight (kg)

  ZK-IWB65BE: 38Kg
  ZK-IWB75BE: 52.5Kg
  ZK-IWB86BE: 65.5Kg

• Package Dimensions (L × W × H)

  ZK-IWB65BE: 1640×185×1010 mm
  ZK-IWB75BE: 1860×185×1125 mm
  ZK-IWB86BE: 1860×185×1125 mm

• Weight with Packaging (kg)

  ZK-IWB65BE: 46Kg
  ZK-IWB75BE: 62.5Kg
  ZK-IWB86BE: 73Kg

• Case Material

  Aluminum alloy and engineered metal framework

• Color

  Black

• Environment

• Operating Temperature

  0°C to 40°C

• Storage Temperature

  10°C to 60°C

• Operating Humidity

  20% to 80% RH (Non-condensing)

• Storage Humidity

  10% to 60% RH (Non-condensing)

• Accessories

• Cables

  Power Cable*1
  USB Cable*1
  HDMI Cable*1

• Remote Controller

  1

• Wall mount

  1

• Stylus Pen

  2

• Eraser

  1

• Peripheral Accessories(Optional)

• Movable bracket

  YES

• OPS

  YES

• Wireless Dongle

  YES
