Paramètres

• Software Specifications

• Operating System

• Server-Side

  Windows 7 Pro/ Ultimate** SP1,
  Windows 2008 Server R2 (64-bit only),
  Windows 2012 Server,
  Windows 2012 Server R2,
  Windows 2016 Server,
  Windows 8.1 Pro,
  Windows 10 Pro / Enterprise or Windows 2019 Server
  Windows 11

• Client-Side

  Windows 7 Pro / Ultimate* SP1,
  Windows 8.1 Pro / Enterprise,
  Windows 10 Pro / Enterprise or
  Windows 2019 Server
  Windows 11

• Suggested Browser for Client-Side

  IE 11 or later,
  Chrome 33 or later,
  Safari 6.1.3 or later
  Edge

• Certifications

  ISO / IEC 27001:2013, ISO / IEC 27701:2019, ISO9001, ISO20000.

• Database Platform

• Maximum Number of ClientsAllowed to Access

  Unlimited (depending on the performance of the server & network)

• Maximum Supported Admin Users

  Unlimited (depending on the performance of the server & network)

• Maximum Supported Personnel

  300,000

• Maximum RFID Cards

  300,000

• Maximum Passwords

  300,000

• Maximum Fingerprints

  300,000

• Maximum Faces

  300,000

• Maximum Access Controlled Doors

  5,000

• Maximum Access Control Levels

  Unlimited(depending on the performance of the server & network)

• Maximum Attendance Points

  2,000

• Maximum Visitors (Monthly)

  100,000

• Maximum Surveillance Cameras

  1024

• Maximum Intelligent Video Servers

  50

• Maximum Controlled Outputs Maximum Inputs

  Unlimited (depending on the device's configuration)

• 3rd-Party Integration

• Notification / Messages

  Line / WhatsApp / Amazon SNS / SMS

• GIS Map

  Google Map / Baidu Map / SuperMap

• Microsoft Active Directory

  No Version restriction

• Intrusion Alarm Integration

  Bosch / RISCO

• API

  Restful API Supports:
  Person Interface of Attendance Area RESTful API
  Person Interface RESTful API
  Person Biometric Template Interface RESTful API
  Card Interface RESTful API
  Department Interface RESTful API
  Area Interface RESTful API
  Reader Interface RESTful API
  Media Interface RESTful API
  Door Interface RESTful API
  Floor Interface RESTful API
  Access Control Interface RESTful API
  Access Control Device Interface RESTful API
  Access Level RESTful API
  Access Control Transaction Interface RESTful API
  Attendance Transaction Interface RESTful API
  Attendance Device Interface RESTful API
  Elevator Control Level Interface RESTful API
  Elevator Device Interface RESTful API
  Elevator Transaction Interface RESTful API
  Vehicle Management Authorization Interface RESTful API
  Vehicle Management Transaction Interface RESTful API
  Visitor Reservation Interface RESTful API
  Visitor Level Interface RESTful API
  Visitor Registration Check Out Interface RESTful API
  Temperature Transactions Interface RESTful API
  FaceKiosk Device Interface RESTful API
  FaceKiosk Area Interface RESTful API

• Database Mapping

  Supports

• Cybersecurity

• Data Protection

  256-bit AES encryption

• Minimun Server Configurations

• Server Quantity

  Single Server
  Single Server
  Multi- Server

• Usage

  Single Server: Within 200 Terminals
  Single Server: Within 1000 Terminals
  Multi- Server: Within 2000 Terminals

• Recommended Database

  1. PostgreSQL (built-in)
  2. SQL Server or Oracle (must be installed by the customer)
  3. It's recommended to install the SQL Server or Oracle on remote server

• Server OS

  Windows 7 / 10 /11
  Windows Server 2008 / 2012 / 2016 / 2019

• Screen Resolution

  At least 21.5 inches, the best resolution is recommended: 1920*1080

• Ethernet Port

  NIC (Network Interface Card) 1000Mbps or Gigabit Ethernet or better

• RAM

  Single Server: 8GB DDR4
  Single Server: 16GB DDR4
  Multi- Server: 16GB DDR4

• CPU

  Single Server: Intel(R) Core(TM) i5 9th Gen series 4 Core processor with speed of 2.7GHz or above
  Single Server: Intel(R) Core(TM) i5 9th Gen series 4 Core processor with speed of 2.7GHz or above
  Multi- Server: Intel(R) Core(TM) i7 9th Gen series 8 Core processor with speed of 3.7GHz or above

• Hard Disk Space

  500GB / 1TB free space or larger (NTFS recommended)

• Graphics Card (Optional)

  Intel Integrated Graphics with above 2GB memory (e.g., Intel® HD Graphics 520) or Discrete Graphics Card at least 1GB memory (e.g., GeForce GTX 550 Ti)

• Video Live Viewing Workstation Recommendations

• CPU

  Intel(R) Core(TM) i7 9th Gen series 8 Core processor with speed of 3.7GHz or above

• RAM

  16GB DDR4 and above

• Graphics Card

  GTX16 series or above

• GPU

  NVIDIA

• Screen Resolution

  1920*1080 or above

• Server OS

  Windows10 (64Bit) or above

• Network card

  Gigabit
