Paramètres

• Model

  SenseFP M2
  SenseFace M2F-LR

• Display

  2.8"@ TFT Color LCD Screen (320*240)

• Camera

  SenseFP M2: N/A
  SenseFace M2F-LR: Binocular Camera @ 1MP

• Operation System

  Linux

• Hardware

  SenseFP M2: CPU: Dual Core@1GHz; RAM: 512MB; ROM: 8GB; Speaker: 8ohm @1W; Physical Keypad: 16 Keys; Fingerprint Sensor: ZK Optical Sensor; Casing color: Black and White
  SenseFace M2F-LR: CPU: Dual Core@1GHz; RAM: 512MB; ROM: 8GB; Speaker: 8ohm @1W; Supplement Light: Yes; Physical Keypad: 16 Keys; Fingerprint Sensor: ZK Optical Sensor; Casing Color: Black and White

• Authentication method

  SenseFP M2: Fingerprint / Card / Password (Physical Keypad)
  SenseFace M2F-LR: Fingerprint / Face / Card / Password (Physical Keypad)

• Fingerprint Capacity

  SenseFP M2: 3,000 (1:N) (Standard)
  SenseFace M2F-LR: 1,000 (1:N) (Standard)

• Face Capacity

  SenseFP M2: N/A
  SenseFace M2F-LR: 500 (1:N) (Standard)

• Card Capacity

  SenseFP M2: 3,000 (1:N) (Standard)
  SenseFace M2F-LR: 1,000 (1:N) (Standard)

• User Capacity

  SenseFP M2: 3,000 (1:N) (Standard)
  SenseFace M2F-LR: 1,000 (1:N) (Standard)

• Transaction Capacity

  150,000 (1:N)

• Max. User Password Length

  8 Digits

• Biometric Authentication Speed

  SenseFP M2: less than 1 sec (Fingerprint)
  SenseFace M2F-LR: less than 1 sec (Fingerprint); less than 1.2 sec (Facial Authentication)

• Touchless Biometric Recognition Distance

  SenseFP M2: /
  SenseFace M2F-LR: 50cm to 180cm (Facial Authentication)

• False Acceptance Rate (FAR) %

  SenseFP M2: FAR ≤ 0.0001% (Fingerprint )
  SenseFace M2F-LR: FAR ≤0.02% (Visible Light Facial Authentication) ; FAR ≤ 0.0001% ( Fingerprint )

• False Rejection Rate (FRR) %

  SenseFP M2: FRR ≤ 0.1% (Fingerprint )
  SenseFace M2F-LR: FRR ≤ 0.05% (Visible Light Facial Authentication); FRR ≤ 0.1% (Fingerprint )

• Biometric Algorithm

  SenseFP M2: ZKFingerprint V13.0 (Standard) / V10.0 (Optional)
  SenseFace M2F-LR: ZKFace V4.0; ZKFingerprint V13.0 (Standard) / V10.0 (Optional)

• Card Type

  ID Card@125 kHz (Standard)
  IC Card@13.56 MHz (Optional)

• Standard Functions

  ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple Authentication Methods, HTTPs / SSH Backend Access, T9 Keyboard (Input)

• Optional Functions

  IC Card, Wi-Fi, Backup Battery

• Power Supply

  DC 12V 3A

• Backup Battery (Optional)

  2,000 mAh (Lithium Battery)
  Max. Operating Hours: 4 Hours
  Max. Standby Hours: 7 Hours
  Estimated Charging Time: 5 Hours

• Operating Temperature

  -5°C to 45°C

• Operating Humidity

  10% to 90% RH (Non-condensing)

• Dimensions

  154 mm*138 mm*34 mm (L*W*H)

• Gross Weight

  SenseFP M2: 0.99 kg
  SenseFace M2F-LR: 1.03 kg

• Supported Software

  Mobile App: ZKBio Zlink
  Cloud-based Software: ZKBio Zlink
  On-Premise Software: ZKBio Time

• Installation

  Wall-mount (Compatible with Asian Gang Box / Single Gang Box)

• Certifications

  ISO14001, ISO9001,CE, FCC, RoHS
