Paramètres

• Model Name

  Saturn-T1000 Series

• Audio Indicator

  Buzzer

• Visual Indicator

  LED Indicator
  Blue: Standby
  Green: Access Granted
  Red: Alarm / Error

• Display

  N/A

• Lane Type

  Single lane
  (Support bi-directional entry / exit lane)

• Barrier Movement Type

  Rotating (Tripod)

• Lane Width

  550 mm

• Motor

  Not specified

• Movement Speed

  N/A

• Movement Accuracy

  N/A

• Clutch

  N/A

• Lid Material

  Polycarbonate + 2.5D tempered glass

• Lid Options Authentication Methods

  RFID / Facial Recognition / QR code (Dynamic / Static)

• Chassis Material

  Cold-rolled SPCC Steel (GB700) (with powder coating finishing)

• Chassis Color

  Pearl White (PWH)

• Tripod Rod Materia

  SUS304 Stainless Steel

• IR Sensors

  N/A

• Motherboard Function

  System mode configuration. Access mode configuration

• Motherboard Communication

  Fire alarm Port (Relay)*1, RS485 port *1

• Controller

  Access controller Options: C3, InBio series or third-party controller subject to turnstile chassis space

• Credential Options

  Post mount Facial Recognition Device: G4 Pro
  Under mount QR code Reader: QR500
  Under mount RFID Reader: ProID10

• Flow Rate

  Face: 15 Passengers per minute
  RFID: 25 Passengers per minute
  QR code: 25 Passengers per minute

• Accessibility

  N/A

• Power Supply

  AC 110V~220V, 50/60Hz, DC 12V

• Power Rating

  Operating: 40W, Standby: 10W

• Fire Signal

  Input for voltage-free contact

• Noise Level

  < 65 dB

• MTTR

  N/A

• Weight

  25 kg

• Dimensions ( L*W*H )

  1200 * 734 * 1020 mm

• Dimensions of Product Parts with Packaging ( L*W*H )

  1300 * 305 *1106 mm

• Certifications

  CE, FCC

• Operating Temperature

  -20°C to 70°C

• Ingress Protection Rating

  Self-laboratory test: equivalent to IPX4

• Operating Humidity

  20% to 80% RH (Non-condensing)

• Supported Software

  ZKBio CVAccess / ZKBio CVSecurity (Compatible with software only when connected to the control panel)

• Safety Features

  Auto drop arm during power failure and re alarm emergency

• Security Features

  Anti-tailgating

• Product Delivery

  Pre-assembled

• Application Environment

  Indoor / Outdoor (If sheltered)

• Site Preparation

  Flat and level finished floor (optional base plate for unfinished floors)

• Security Level

  Middle

• Emergency Mode

  Drop arm function engages during power outage or fire alarm events

• Packing Material

  Carton box
