Paramètres

• Model

  SL02-ZL140H

• Material

• Housing Material

  Aluminum Alloy

• Front Panel

  ABS

• Color

  Black

• Mortise Lock

• Type

  American Standard

• Backset

  62mm (2-7/16")

• Axe Distance

  Lever to Cylinder: 95mm (3-3/4"),
  Lever to Thumbturn: 62mm (2-7/16")

• Square Spindle

  8x8mm square

• Faceplate (H×W)

  26×204 mm (1-1/41" x 8-1/32"), squared standard

• Built-in Detectors

  Latch Bolt, Deadbolt, Cylinder

• Technical

• Unlocking Methods

  Card, Web Application, Mechanical Key Backup

• Capacity

  Event Log: 500 entries (Auto-overwrite)

• Card Reader

  S50/S70 IC Card @13.56 MHz

• NFC Supported

  Yes ( ISO/IEC 14443 A)

• Encoder

  D147-H

• Audio Prompt Language

  English

• Wireless Communication

  Zigbee 3.0 (IEEE 802.15.4)

• Power Supply

  4 × LR6 AA (Alkaline recommended only)

• Battery Life

  Approximately 1 year and 7 months
  (* Based on lab testing: 10 daily cycles with deadbolt actuation and Zigbee connected.)

• Supported Software

  ZKBio CVSecurity SmartLock

• Door Compatibility

• Door Type

  Swing Mortise Door

• Door Thickness

  40 to 63 mm (Standard)

• Door Swing

  Right Inward (Standard). (For non-standard door swing, please specify at purchase for proper fit.)

• General

• Net Weight

  2.3 kg

• Gross Weight

  2.7 kg

• Product Dimensions (H×W×T)

  Exterior: 330 × 71 × 22 mm
  Interior: 330 × 71 × 22 mm
  * Excluding lever height: 41 mm

• Package Dimensions (L×W×H)

  460 × 240 × 95 mm

• Operating Temperature

  -20°C to 55°C (-4°F to 131°F)

• Operating Humidity

  5% to 95% RH (Non-condensing)

• Certifications

  CE, FCC

• Package Contents

  Front/Rear Trim;
  Washer; Lock Body Kit (Includes mortise, strike plate, locking box);
  Lock cylinder Kit (Includes 2 mechanical keys);
  Studs & Screws Kit; IC Card * 2; Installation Template;
  Installation Guide
