Paramètres

• Outdoor station

• System

  Linux OS

• Video Compression

  H.264

• Image Sensor

  1/2.7” 2MP CMOS

• Wide Dynamic Range (WDR)

  Yes (120°)

• Maximum View Angle

  138° (H), 105° (V)

• Day/Night

  Color Image

• Infrared Light

  Support 10 meters IR night vision

• Minimum Illumination

  0.001 Lux

• Audio Input

  Microphone*1 (Omni-directional)

• Audio Output

  Built-in Speaker

• Bi-directional Talk

  Support two-way talk

• Communication

  Wi-Fi (IEEE 802.11 a/b/g) @ 2.4 GHz
  RS485: ZKTeco RS485*1

• Ingress Protection Rating

  IP55

• Installation Method

  Flush Mount (flat surface); Rain
  Cover*1

• Casing Material

  Aluminium Alloy

• Power Supply

  12 VDC, 2A
  PoE (IEEE 802.3af/ at)
  Power supply by indoor monitor

• Power Consumption

  Standby≤2 W; Operating≤7 W

• Operating Temperature

  –30 °C to +60 °C

• Operating Humidity

  20% to 95% RH (Non-condensing)

• Dimensions (H*W*D)

  125*45*27(mm)

• Weight

  0.25kg

• Indoor monitor

• System

  Linux

• Resolution

  1024*600

• Power supply

  PoE (IEEE 802.3 af/ at) DC 15V/1.2A

• Standby Power

  ≤1W

• Operating Power

  ≤10 W

• TF card

  Max 64GB

• Button

  Virtual button on the touch screen

• Interfaces

  Network Cable Port*1

• Support Wi-Fi

  ( IEEE 802.11 a/b/g) @ 2.4 GHz

• Unlock signal output*1

  NO / NC port

• Installation Method

  Wall mount

• Supported Mobile App

  ZSmart

• Material

  Tempered glass panel + ABS plastic

• Dimensions(W*H*D)

  195*132*18(mm)
