Paramètres

• Model

  F35

• Display

  2.4"@ TFT Color LCD Screen (720*1280)

• Camera

  Camera @ 2MP

• Field of View

  Diagonal: 145°
  Horizontal: 118°
  Vertical: 62°

• Operation System

  Linux

• Hardware

  CPU: 1.2GHz Dual Core
  RAM: 256MB; ROM: 512MB
  Speaker: 8ohms±20% @1.0W
  Microphone: *1 (Sensitivity: -29 to -35 dB / Omni-directional / Signal-to-Noise Ratio: 58 dB / Impedance: 2.2 kΩ
  Fingerprint Sensor: In-Glass Fingerprint (Z-ID)

• Authentication Method

  Fingerprint / Card / Password (Physical Touch Keypad )

• User Capacity

  10,000 (1:N)

• Card Capacity

  10,000 (1:N)

• Fingerprint Template Capacity

  10,000 (1:N)

• Transaction Capacity

  500,000

• Max. User Password Length

  6 to 8 Digits

• Biometric Verification Speed

  less than 0.3 sec (Fingerprint)

• False Acceptance Rate (FAR) %

  FAR ≦ 0.0001% (ZKFingerprint V10.0)

• False Rejection Rate (FRR) %

  FRR ≦ 0.01% (ZKFingerprint V10.0)

• Biometric Algorithm

  ZKFingerprint V10.0

• Support Card Type

  ID Card@125 kHz (Standard)
  Optional Multi-Tech Module:
  Module1: ID & IC & DESFire EV1 / EV2; (125 kHz & 13.56 MHz Dual Frequency)
  Module 2: ID & IC & DESFire EV1 / EV 2 & FeliCa & Legic & HID Prox (125 kHz & 13.56 MHz Dual Frequency)
  Module 3: ID & IC & DESFire EV1 / EV2 & FeliCa & Legic & HID Prox & HID iClass (125 kHz & 13.56 MHz Dual Frequency)

• Communication

  TCP/IP*1
  Wi-Fi (IEEE802.11a/g/n) @ 2.4 GHz
  Wiegand (Input & Output)*1
  RS485: ZKTeco RS485 *1
  Aux Inputs *1, Aux Outputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1, Doorbell*1

• Standard Functions

  Webserver, ADMS, DST, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti Passback, Record Query, Tamper Switch Alarm, Multiple Verification Methods Video Door Phone, ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push, Protocol Switch, HTTPS / SSH Backend Access, T9 Keyboard (Input)

• Optional Functions

  ZSmart, SIP Client (Ver2.0), Wi-Fi, IC Card, Multi-Tech Module: Module 1 / Module2 / Module 3,Wireless Doorbell

• Access Control Interface

  RS485 (DM10 Controller 1 Door Expansion (Coming soon) / RS485 Card Reader / Fingerprint Reader)

• Power Supply

  DC 12V 3A

• Operating Temperature

  -5℃ to 55℃ (23 ℉ to 131 ℉ )

• Operating Humidity

  10% to 90% RH (Non-condensing)

• Dimensions

  195 mm*75 mm*25.35 mm (L*W*H)

• Gross Weight

  1.13 Kg

• Net Weight

  0.52 Kg

• Supported Software

  Software: ZKBio CVAccess / ZKBioTime
  Mobile App: ZSmart

• Installation

  Wall-mount (Compatible with Asian Gang-box / Single Gang-Box / European Gang-Box)

• Housing Material

  Aluminium Alloy

• Ingress Protection Rating

  IP65 (waterproof and dustproof )
  IK04 (Vandal Resistant)

• Certifications

  ISO14001, ISO9001, CE, FCC, RoHS

Télécharger

(Les membres Argent et supérieurs peuvent télécharger après s'être connectés)

• Nom
• Type
• Taille
• Date de mise à jour

• PDF

  ZK_F35_UM_20240903

  Manuel d’utilisation

  6.52MB

  2024-09-05

  Télécharger

• PDF

  F35_Datasheet_20240723.pdf

  Fiche technique

  413.55KB

  2024-07-23

  Télécharger

• PDF

  ZK_F35 QSG_EN_v1.1_202403

  Guide d’utilisation rapide

  2.99MB

  2024-03-11

  Télécharger
