Paramètres

• Model Name

  FBL6000 Pro
  FBL6200 Pro

• Audio Indicator

  Speaker

• Visual Indicator

  LED pictograms
  Steady green arrow = normal use
  Steady red cross = door closing

• Display

  N/A

• Lane Type

  FBL6000 Pro: Single lane
  FBL6200 Pro: Dual flap barriers for additional lane

• Lane Width

  600 mm

• Lane Height

  994 mm

• Barrier Movement Type

  Retractable Flap barrier
  (Acrylic / Optional: Tempered Glass)

• Motor

  DC brushless motor

• Movement Speed

  0.6s to 1s

• Movement Accuracy

  1.5 Degree per movement

• Clutch

  N/A

• Cabinet Material

  SUS304 Stainless steel

• Lid Material

  SUS304 Stainless steel

• IR Sensors

  Equipped with 5 pairs (standard). Support up to 9 pairs (optional).

• Motherboard Function

  System configuration, access mode configuration, anti-tailgate configuration.

• Motherboard Communication

  Fire alarm port (Relay)*1, RS485 port*1

• Controller

  C3 series controller/ InBio series controller (optional).
  3rd-party controller subject to turnstile chassis space.

• Credential Options

  RFID reader: ProID10;
  Fingerprint reader: FR1500S or 3-rd party readers;
  QR Code reader (Static / Dynamic): QR500;
  Facial authentication terminal (Post mount): G4 Pro

• Flow Rate

  Facial Recognition: 30 passengers per minute;
  RFID: 20 passengers per minute;
  Fingerprint: 15 passengers per minute ;
  QR Code: 30 passengers per minute

• Accessibility

  Standard lane (600mm) : adult

• Power Supply

  AC110-220, 50/60 Hz

• Power Rating

  40W

• Fire Signal

  Input for voltage-free contact

• Noise Level

  Less than 60 dB

• MCBF

  >5 million

• Net Weight

  FBL6000 Pro: 100 kg
  FBL6200 Pro: 70 kg

• Gross Weight

  FBL6000 Pro: 150 kg
  FBL6200 Pro: 90 kg

• Dimensions ( L*W*H )

  FBL6000 Pro: 1414 * 300 * 994 mm
  FBL6200 Pro: 1414 * 300 * 994 mm

• Dimensions with Packing ( L*W*H )

  FBL6000 Pro: 1510 * 780 * 1230 mm
  FBL6200 Pro: 1510 * 400 * 1230 mm

• Operating Temperature

  -20°C to 70°C

• Operating Humidity

  0% to 95% RH (non-condensing)

• Certifications

  CE, FCC

• Ingress Protection

  IPX4

• Supported Software

  ZKBio CVAccess / ZKBio CVSecurity
  (Depends on equipped access controller)

• Safety Features

  Power off unlock device / Fire alarm active door release

• Security Features

  Anti-intrusion, wrong way enter alarm
  Automatically close / lock door no one pass

• Product Delivery

  Pre-assembled for easy installation

• Application Environment

  Indoor and Outdoor

• Site Preparation

  Flat and level finished floor (optional base plate for unfinished floors)

• Security Level

  Middle

• Emergency Mode

  Flap barrier unlocks automatically during emergencies

• Packing Material

  Wooden Box
