Paramètres

• Scanning Performance

• Scan Mode

  Automatic Scanning

• DPI

  1024 x 1024 pixels

• Decode Capabilities

  1D: Codabar, Code39, Code32Pharmaceutical (PARAF), Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5Industial, Straight 2 of 5 IATA, Matrix 2 of 5, Code11, Code128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBarLimited, GS1 DataBar Expanded, China Post(Hong Kong 2 of 5), Korea Post;
  2D: Codeblock A, Codeblock F, PDF417, Micro PDF417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN.

• Motion Tolerance

  4 m/s

• Scan Range

  0-280mm (EAN13 13mil 90%PCS)

• Field of View

  Horizontal: 44°; Vertical: 34

• Scan Angle

  Turn±360°, Elevation±65°, Declination±65°

• Illumination

  630nm red LED

• Prompt Method

  Indicator light, Buzzer (Adjustable tone and volume)

• Button

  Support manual reading mode

• Interface

  RJ45

• Data Communication Support

  USB (Drive-Free), RS232

• Physical Parameters

• Dimensions (L*W*H)

  97 * 98 * 159 (mm)

• Weight

  333g

• Material

  ABS + PC

• Cable

  2m

• Environmental Parameters

• Operating Temperature

  -20°C to 60°C

• Storage Temperature

  -30°C to 70°C

• Relative Humidity

  5% to 95%RH (non-condensing

• Drop Tolerance

  Designed to withstand multiple drops at 1.5 m to concrete ground

• Ambient Light Immunity

  0 to 100000 Lux

• Electrical Parameters

• Input Voltage

  DC 5V±5%

• Working Current

  240mA
